Nylon 66 (also known as polyamide 66) reinforced with 30% glass fiber is a high-performance material that combines strength and durability. This engineered nylon is ideal for applications requiring tough yet lightweight materials, providing excellent performance in demanding environments.
Nylon 66 GF30 offers superior thermal stability, making it highly resistant to heat up to 120°C without losing its strength. This makes it suitable for use in industries such as automotive, electronics, and manufacturing, where high temperatures are common.
However, like other polyamides, Nylon 66 is hygroscopic and absorbs moisture from the air. To ensure the best results during processing, it’s important to pre-dry the material at 80°C to 100°C for 4-6 hours before molding. Proper predrying guarantees that the material maintains its mechanical strength, ensuring reliable performance and high-quality products.
Regular nylon is strong, but when you add glass fiber, it becomes even tougher. PA66 GF25 can resist heat, chemicals, and physical damage much better than standard nylon. This makes it perfect for making things like engine parts or even furniture, where long-term durability is important.
This reinforced polyamide is used across various industries due to its high strength and durability. It’s often found in automotive parts, electrical housings, and mechanical components like gears and brackets. The material’s ability to withstand harsh conditions makes it a top choice for products that require longevity and resilience.
The combination of glass fiber reinforcement and engineered nylon results in a lightweight, durable material that resists heat, wear, and chemical exposure. Additionally, its recyclability makes it an eco-friendly option. With proper processing, Nylon 66 GF30 delivers excellent performance, ensuring that your products remain strong and reliable over time.
Mechanical strength | parameter | value | unit | norm |
Tensile strength | 50mm/min | 180 | Mpa | ISO 527-2 |
Elongation at Break | 50mm/min | 4 | % | ISO 527-2 |
Flexural Strength | 2mm/min | 270 | Mpa | ISO 178 |
Flexural Modulus | 2mm/min | 8500 | Mpa | ISO 178 |
Izod Notched Impact Strength | 23℃ | 13 | kJ/m2 | ISO 180 |
Thermal performance | parameter | value | unit | norm |
Temperature of Deflection Under Load | 1.8MPa | 235 | ℃ | ISO 75 |
Temperature of Deflection Under Load | 0.45MPa | 245 | ℃ | ISO 75 |
Melting temperature | / | 250 | ℃ | ISO 11375 |
典型加工条件 Typical processing conditions | ||
注塑条件/Injection molding condition | 单位 | 典型值 |
干燥温度/Drying temperature | ℃ | 80~120 |
干燥时间/Drying time | h | 2~6 |
熔融温度/Melting temperature | ℃ | 270~300 |
注塑温度-喷嘴/Injection temperature – Nozzle | ℃ | 280~300 |
注塑温度-前段/Injection molding temperature – front section | ℃ | 270~280 |
注塑温度-中段/Injection molding temperature – middle section | ℃ | 275~290 |
注塑温度-后段/Injection molding temperature – post segment | ℃ | 280~300 |
模具温度/ Mold temperature | ℃ | 80~120 |
Electrical properties | parameter | value | unit | norm |
Surface resistivity | / | 1015 | Ω | / |
Volume resistivity | / | 1015 | Ω·cm | / |
Other properties | parameter | value | unit | norm |
Water absorption | 24h（23℃） | 0.7 | % | ISO 62 |
Flammability | / | HB | class | UL94 |
Glass fiber filler | 1h（600℃） | 30 | % | ISO 3451 |
The box features a transparent window, elegantly framing the wooden hearts inside. This design not only showcases the beauty of the hearts but also allows for easy viewing of the heartfelt messages within, making it a beautiful keepsake that can be displayed and cherished for years to come.
The box features a transparent window, elegantly framing the wooden hearts inside. This design not only showcases the beauty of the hearts but also allows for easy viewing of the heartfelt messages within, making it a beautiful keepsake that can be displayed and cherished for years to come.
The box features a transparent window, elegantly framing the wooden hearts inside. This design not only showcases the beauty of the hearts but also allows for easy viewing of the heartfelt messages within, making it a beautiful keepsake that can be displayed and cherished for years to come.
Frequently asked questions about Engineered Polyamide Compound manufacturing
Our preferred payment methods are T/T. However, we are open to discussing L/C, Paypal upon request.
Yes, we conduct 100% testing on all goods prior to delivery.
We are a polyamide factory.
Engineered polyamide compounds are used in various industries such as automotive parts, electrical components, consumer goods, and industrial machinery. They are commonly found in gears, bearings, electrical housings, and under-the-hood automotive components due to their durability and resistance to heat and chemicals.
Standard delivery time is 7-14 days if the item is in stock. If not, it may take 15-20 days to arrange shipment.
Yes, we can match material colors based on your specified Pantone or RAL number.
